A gravel bike from Revel?! Yep, Revel is better known for our shreddy mountain bikes with legendary CBF suspension, but a little-known fact is most of the team at Revel ride gravel bikes at least as much as they ride mountain bikes. Material geeks at heart Revel always like to use the right material for the right application. However, gravel bikes are where the waters get a little muddy. We’ve been riding titanium since we launched it in 2016 and it has gotten glowing reviews, but Revel all wanted a carbon version too.

Revel knew they could make a pretty neat gravel bike by taking full advantage of the ability to shape carbon exactly how we want and truly optimize the ride quality.



Wheel Size 700c (27.5 compatible)
Front Travel 000mm
Rear Travel 000mm
Hub Spacing 142x12mm rear / 100x12mm front
Axle Spec 166x12x1.0mm rear / 123.5x12x1.0mm
Seatpost Diameter 27.2mm
Seatpost Insertion Depth SM (200mm), MD (250mm), LG (275mm), XL (300mm), XXL (320mm)
Cable Routing Internal (incl. Dropper)
Rear Brake 140mm mount / 160mm max
Brake Rotors Centerlock rotors with internally serrated lockrings only.
Tire Clearance 700x50mm, 27.5×2.1
Bottom Bracket BSA 68mm English Threaded
Max Chainring 50T Round (47.5mm Chainline) / 46T ROUND (45mm Chainline) / OVAL TBD
Headset IS42 Upper / IS52 Lower
Colors T1000 / Mint
Sizes S / M / L / XL / XXL
Frame Warranty Lifetime Warranty (Details HERE)


Brand Revel Bikes
Type Revel Bikes and Frames
