Revel Rascal: 29ER Wheels; 130MM Rear / 140MM Front

The Rascal lives up to its name- it is a sleek-looking machine that is mischievously fast, nimble, and adept. Think capability and playfulness in both ascend and full send mode. Revel's vision for the Rascal was to deliver a confidence-inspiring and ultra-versatile mountain bike in all applications. The Canfield Balance Formula is the heart of every Revel bike, which maximizes the amount you pedal in the sweet spot. The Rascal is a fast and capable mountain bike in a sleek package that you can ride every day, regardless of terrain.

Got a question? Send us an email to sales@offroadbikesonline.com.au

Pictures for reference only.

How does it work?

Basically, You select your frame size, colour, required dropper length (31.6mm dropper required), bar, and stem size and let us take care of the rest!

Build Information:
This bike will be shipped un-built in its standard bike box. Off Road Bikes Online strongly recommend that this bike be built by a trained mechanic, at a bike shop, or a mobile bike mechanic. Any assembly undertaken without professional assistance is at the customer's risk and any damage resulting from faulty assembly will not be covered by the warranty.

Still not convinced?

We know how important it is for riders to get your leg over your dream rig on your local trails, so we created ORBOs rental/Demo program! Check it out HERE!

Frame Specs:
Wheel Size	29 inch
Front Travel	140mm
Rear Travel	130mm
Shock Spec	210 x 50-22.2 x 8 Hardware Spec
Boost Axles	148mm rear / 110mm front
Seatpost Diameter	31.6mm (use the size guide to choose the best dropper height!)
Bearings	BOLU 6801 VRS full complement, 12mm x 21mm x 5mm 18pcs per bike
Rear Brake	180mm post mount / 203mm max
Tire Clearance	29in x 2.4 (CEN Standard: 2.4)
Bottom Bracket	Threaded (73mm English threaded)
Chainguide	Custom Revel guide included
Tapered Headtube	IS42 upper / IS52 lower
Colors	Alaska / T1000
Sizes	S / M / L / XL
Frame Warranty	Lifetime Warranty
